WHICH CIRCUIT TRACER IS RIGHT FOR YOU?
SURETRACE™ PLUS CIRCUIT TRACER
SURETRACE™ CIRCUIT TRACER
SURETRACE™ PRO CIRCUIT TRACER
CLICK TO COMPARE
SURETRACE™ CIRCUIT TRACER
SURETRACE™ PLUS CIRCUIT TRACER
SURETRACE™ PRO CIRCUIT TRACER
SURETRACE™ CIRCUIT TRACER
SURETRACE™ PLUS CIRCUIT TRACER
SURETRACE™ PRO CIRCUIT TRACER
SURETRACE™ CIRCUIT TRACER
SURETRACE™ PLUS CIRCUIT TRACER
SURETRACE™ PRO CIRCUIT TRACER
Find any energized or de-energized conductive material (breakers, fuses, conductors, wires, data cable)
Easily fault-find breaker trips, opens, dead shorts, and splice errors
Works with 3-phase systems
Safety rating: CATIII 480V
Tests for continuity, eliminating the need for an additional tester on the job
Indicates 24-600V AC/12-600V DC, DC Polarity, and PPE
Works in all conditions and positions with high-visibility rotating main displays and TightSight™ displays (TightSight rotates on SureTrace Pro)
Sense presence of AC voltage from 24 to 600V AC with built in NCVT
Ruggedized hard case
Patent-pending Inductive Sensing Clamp (ISC-950) induces tracing signal and measures/displays 0-600 AC amperage
Reads and displays measured voltage (AC or DC)
Find any energized or de-energized conductive material (breakers, fuses, conductors, wires, data cable)
Easily fault-find breaker trips, opens, dead shorts, and splice errors
Works with 3-phase systems
Safety rating: CATIII 600V
Tests for continuity, eliminating the need for an additional tester on the job
Indicates 24-600V AC/12-600V DC, DC Polarity, and PPE
Works in all conditions and positions with high-visibility main display and TightSight™ display (main display rotates 180°)
Sense presence of AC voltage from 24 to 600V AC with built in NCVT
Ruggedized hard case
Test receptacles for correct wiring
Patent-pending Inductive Sensing Clamp (ISC-950) induces tracing signal and measures/displays 0-600 AC amperage
Reads and displays measured voltage (AC or DC)
Find any energized or de-energized conductive material (breakers, fuses, conductors, wires, data cable)
Easily fault-find breaker trips, opens, dead shorts, and splice errors
Works with 3-phase systems
Safety rating: CATIII 600V
Tests for continuity, eliminating the need for an additional tester on the job
Measures 24-600V AC/12-600V DC and indicates DC Polarity and PPE
Works in all conditions and positions with high-visibility rotating TightSight™ and main display
Sense presence of AC voltage from 24 to 600V AC with built in NCVT
Ruggedized hard case
Test receptacles for correct wiring
Patent-pending Inductive Sensing Clamp (ISC-950) induces tracing signal and measures/displays 0-600 AC amperage
Reads and displays measured voltage (AC or DC)
Test receptacles for correct wiring
