Repair with
Master repairs with efficiency and accuracy. Learn on the job or refresh skills for complex tasks by replacing traditional manuals with augmented reality.
cl
ity
AR
21053
It’s your first day as a service technician!
You’re working on a broken engine that needs an urgent repair, and your first task is to remove the left impulse coupling magneto on an engine, with speed and precision.
The only thing to guide you through this task is an old paper manual of work instructions—but it’s covered in stains, missing some helpful step-by-step images, and cumbersome to flip through and comprehend.
To complete the task on time, click on the manual to read the pages of work instructions and then click on the correct tools and parts in the right order. To submit each selection, click Next Step. Tool and part selections can only be made when the manual is closed––and you won’t know if your selections are correct until your time is up.
Warning! The information, depictions of products, and images contained in this Augmented Reality experience are intended for demonstration purposes only. This experience is not intended or implied to substitute for Instructions for Continued Airworthiness and should not be used for training, maintenance, or repair. THIS EXPERIENCE IS PROVIDED AS IS, WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT.
Disclaimer
The information, depictions of products, and images contained in this Augmented Reality experience are intended for demonstration purposes only. This experience is not intended or implied to substitute for Instructions for Continued Airworthiness and should not be used for training, maintenance, or repair. THIS EXPERIENCE IS PROVIDED AS IS, WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT.
Warning!
GOAL: REMOVE THE left impulse coupling magneto
01:00
Tools
Parts
Clamps (2)
Magneto adapter
Washers (2)
Oil filter
Plug wires
Studs (2)
Magneto
Nuts (2)
Camshaft
1/2” box end wrench
1/2” smart torque wrench
1/2” drive - 6” extensions
3/8” stud extractor / installer
Oil filter wrench
1/2” socket
progress
WORK INSTRUCTIONS
WARNING!
This time, instead of stopping to check each step of a paper manual, you now have augmented work instructions that allow you to follow each step with detailed overlays of digital content onto your real-world environment.
Let's see how you do!
Results
5/5
0:30
Components placed correctly
Time Elapsed
Congratulations! You executed the task correctly in less than a minute; without the help of AR. You must be an expert! Now see how much easier it is with AR, so someone who isn’t an expert like yourself could do it even faster.
STEP 1:
Remove and discard 1. plug wires
1
2
STEP 2:
Use 1. Oil Filter Wrench to remove 2. oil filter
3
STEP 3:
Using the 1. 1/2" socket and 2. 1/2" drive 6" extension, remove the 3. two nuts, 4. two washers, and 5. two clamps from the two studs on the accessory housing
5
4
6
STEP 4:
Remove and discard 1. impulse coupling magneto and 2. magneto adapter
STEP 5:
Using the 1. 3/8" stud extractor/installer, remove and discard the 2. two studs from the left side of the accessory housing
With AR showing you reliable, up-to-date, and easy to understand repair instructions, as a new technician, you acquired critical product knowledge faster, enabling you to complete this complex task efficiently and safely.
Explore the most common use cases for industrial augmented reality that deliver tangible business benefits.
With AR
1/5
1:00
Without AR
play again
